Coffing® Hoists 08230W JLC Single Reeving Electric Chain Hoist with Chain Container, 0.5 ton Load, 10 ft H Lifting, 1 hp Power Rating

Manufacturer #08230W
Call for availability
List Price: $3,345.34
$3,345.34
Quantity Break Pricing may apply in the cart
HSI
HOI20711
UPC #:698303326219
Product Overview
Coffing® Hoists Electric Chain Hoist, Single Reeving, series: JLC, 0.5 ton, 10 ft Lifting Height, 32 FPM Lift Speed, 1-Speed Control, Multiple Disc Motor Brake, 1 hp, 115/230 VAC, White Enamel, 24-1/8 in L x 8-11/16 in W x 8-11/16 in H. Coffing® JLC Hook and Lug Suspension Models are Designed For Industrial Duty Performance. Compact in Size, The JLC Features a Multiple Disc Motor Brake, Overload Clutch and Chain End Stop For Safety.

Features
  • Standard push button drop is 4 ft less than lift
  • Limit switches - adjustable to regulate upper and lower load travel
  • Brass nuts standard for improved repeatability and chain positioning
  • Precision machined alloy steel gears run in oil bath for longer, quieter operation
  • NEMA 3R push button station - ergonomic design fits operator's hand for thumb or two handed operation
  • 24 V control for operator safety
  • Frame - compact aluminum housing for portability and ease of installation
  • Chain containers standard on lifts up to 20 ft single chain/10 ft double chain

Specifications
More Information
Manufacturer Part Number 08230W
Manufacturer Columbus McKinnon Corporation
Brand Name CM
UPC 698303326219
Length (in) 24.125
Width (in) 8.6875
Height (in) 8.6875
Series JLC
Color White Enamel
Standard Approvals
  • CSA Certified
Type Single Reeving
Load Capacity 0.5 ton
Voltage 115/230V AC
Lifting Height 10 ft
Package Quantity 1/Each
