Coffing® Hoists 08253W JLC Double Reeving Electric Chain Hoist, 2 ton Load, 20 ft H Lifting, 1 hp Power Rating

Manufacturer #08253W

Call for availability

$4,917.17

Quantity Break Pricing may apply in the cart

HSI

HOI20732

UPC #:698303326431

Coffing® Hoists 08253W JLC Double Reeving Electric Chain Hoist, 2 ton Load, 20 ft H Lifting, 1 hp Power Rating is available to buy in increments of 1

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Product Overview

Coffing® Hoists Electric Chain Hoist, Double Reeving, series: JLC, 2 ton, 20 ft Lifting Height, 8 FPM Lift Speed, 1-Speed Control, Multiple Disc Motor Brake, 1 hp, 230/460 VAC, White Enamel, 24-1/8 in L x 8-11/16 in W x 8-11/16 in H. Coffing® JLC Hook and Lug Suspension Models are Designed For Industrial Duty Performance. Compact in Size, The JLC Features a Multiple Disc Motor Brake, Overload Clutch and Chain End Stop For Safety.

Features

Standard push button drop is 4 ft less than lift
Limit switches - adjustable to regulate upper and lower load travel
Brass nuts standard for improved repeatability and chain positioning
Precision machined alloy steel gears run in oil bath for longer, quieter operation
NEMA 3R push button station - ergonomic design fits operator's hand for thumb or two handed operation
24 V control for operator safety
Frame - compact aluminum housing for portability and ease of installation
Chain containers standard on lifts up to 20 ft single chain/10 ft double chain

Specifications

More Information
Manufacturer Part Number	08253W
Manufacturer	Columbus McKinnon Corporation
Brands	CM
UPC	698303326431
Length (in)	24.125
Width (in)	8.6875
Height (in)	8.6875
Series	JLC
Color	White Enamel
Standard Approvals	CSA Certified
Type	Double Reeving
Load Capacity	2 ton
Voltage	230/460V AC
Lifting Height	20 ft
Package Quantity	1/Each
