Coffing® Hoists 12013W 12 EC Series Single Reeving Large Frame Electric Chain Hoist, 2 ton Load, 10 ft H Lifting, 3 hp Power Rating

Manufacturer #12013W
Call for availability
List Price: $7,211.13
$7,211.13
Quantity Break Pricing may apply in the cart
HSI
HOI20662
UPC #:698303218538
Product Overview
Coffing® Hoists Electric Chain Hoist, Single Reeving Large Frame, series: EC Series, 2 ton, 10 ft Lifting Height, 24 FPM Lift Speed, 1-Speed Control, Multiple Disc Motor/Mechanical Load Brake, 3 hp, 230/460 VAC, White Enamel, 31-3/16 in L x 14-13/16 in W x 10-7/8 in H. Coffing® EC Hook and Lug Suspension Models are High Performance Hoists Engineered For Heavy Duty Industrial Service. Designed For Safety, The EC Incorporates Mechanical Load Brake, Motor Brake and Overload Clutch as Standard.

Features
  • Standard push button drop is 4 ft less than lift
  • Large frame design features load bearing housings of ductile iron construction for maximum strength, non-load bearing housings of cast aluminum alloy for minimum weight
  • Engineered and designed for use with higher torque 2 and 3 hp three phase motors
  • Durable construction

Specifications
More Information
Manufacturer Part Number 12013W
Manufacturer Columbus McKinnon Corporation
Brand Name CM
UPC 698303218538
Length (in) 31.1875
Width (in) 14.8125
Height (in) 10.875
Series EC
Color White Enamel
Standard Approvals
  • ASME/ANSI B30.16
  • CSA Certified
Type Single Reeving Large Frame
Load Capacity 2 ton
Voltage 230/460V AC
Lifting Height 10 ft
Package Quantity 1/Each
