Crosby® 1020529 S-252 Web Sling Shackle, Bolt Pin, 20.5 ton WLL, 4 in, 1-1/2 in Pin dia
Manufacturer #1020529
In stock
$486.00
$486.00
Quantity Break Pricing may apply in the cart
HSI
FIT10375
UPC #:662547205296
Crosby® 1020529 S-252 Web Sling Shackle, Bolt Pin, 20.5 ton WLL, 4 in, 1-1/2 in Pin dia is available to buy in increments of 1
Product Overview
Crosby® web sling shackle, bolt pin, series: S-252, 20.5 ton working load limit, 4 in diameter, 1-1/2 in bolt pin diameter, 5-1/4 in inner length, 4-1/2 in inner width, 2.12 in opening, 3.12 in eye outer, 9.45 in overall length, 7.19 in overall width, alloy body, alloy pin.
Features
- Each shackle has a product identification code (PIC) for material traceability along with a working load limit and the name Crosby® forged into it
- Increased radius of bow gives wider sling bearing surface resulting in an increased area for load distribution
- Increasing synthetic sling efficiency as compared to standard anchor and chain shackle bows and conventional hooks, this allows 100% of the sling's rated working load limit to be achieved
- Allows better load distribution on internal fibers
- Bolt has a larger diameter that provides better load distribution
- Look for the Red Pin® the mark of genuine Crosby® quality
Specifications
| Manufacturer Part Number | 1020529 |
|---|---|
| Manufacturer | Crosby Group |
| Brands | CROSBY |
| UPC | 662547205296 |
| Length (in) | 9.45 |
| Width (in) | 7.19 |
| Working Load Limit (ton) | 20.5 |
| Series | S-252 |
| Shackle Size | 4 in |
| Design Factor | 5:1 |
| Standard Approvals |
|
| Eye Outer Size (in) | 3.12 |
| Pin Diameter | 1-1/2 in |
| Opening Size | 2.12 in |
| Inner Length | 5-1/4 in |
| Inner Width | 4-1/2 in |
| Type | Web Sling |
| Package Quantity | 1/Each |
