Dixon® 6HTF6-SS HT Series Flush Face Coupling, 3/4-14 Nominal, FNPT, 316 Stainless Steel
Manufacturer #6HTF6-SS
In stock
List Price:
$520.00
$520.00
Quantity Break Pricing may apply in the cart
HSI
6HTF6-SS-10639
Product Overview
Dixon® Flush Face Coupling, Series: HT Series, 3/4-14 Nominal, FNPT, 1-1/2 in Hex, 3.7 in Length, 5000 psi, 316 Stainless Steel, 1.85 in OD
Features
- Machined components are manufactured using solid bar stock
- Easily rebuildable
- Bulkhead mountable sleeve for breakaway, multi-plate or Blindmate installations
- DORS (dual opposing retention spheres) retention system prevents valve stem ejection during surge flow and pressure spike conditions
- High flow performance, compact profile
- Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life
- Steel componentry is plated using ROHS compliant trivalent chrome
- Steel coupler sleeves are hardened to resist deformation and maximize service life
- Couplers have polyurethane valve stem O-Ring, with a temperature range of -65 to 212° F
Specifications
Manufacturer Part Number | 6HTF6-SS |
---|---|
Manufacturer | Dixon Valve & Coupling |
Brand Name | DIXON |
Length (in) | 3.7 |
Height (in) | 1.85 |
Hex Size | 1-1/2 in |
Material | 316 Stainless Steel |
Nominal Size | 3/4 in - 14 |
Standard Approvals |
|
Package Quantity | 1/Each |
