Dixon® R125CS-A 520-H Ferrule, 1-1/4 in ID x 1-51/64 to 1-54/64 in OD Nominal, Hose, 1-1/4 in L, Brass, Domestic

Manufacturer #R125CS-A
In stock
List Price: $13.31
$13.31
Quantity Break Pricing may apply in the cart
HSI
R125CS-A-10639
Product Overview
Dixon® Ferrule, Series: 520-H, 1-1/4 in ID x 1-51/64 to 1-54/64 in OD Nominal, Hose End Style, 1-1/4 in Length, Brass, 2-1/32 in dia, Domestic

Features
  • May also be used with internally expanding permanent couplings scovill style
  • Coupling procedures, ferrule recommendations and API test data are available upon request, please contact Dixon
  • Consult Dixon for other hose OD's
  • Do not interchange with other manufacturer's fittings
  • Dixon holedall stems and ferrules are specifically designed to be used together as a coupling system
  • Do not use a wrench or vice on ferrule
  • Holedall couplings, regardless of coupling style, are never to be used for steam service at any pressure
  • Holedall fittings are not to be used with cable reinforced high pressure hose, 4 or 6 braid wire hydraulic hose or any other service not listed in the recommendations
  • Strict adherences to ferrule OD range (Internally Expanded) for each hose end to be assembled is essential for satisfactory performance
  • Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting
  • The assembly's (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure
  • Media being transported through the hose should be compatible with the stem material
  • Compatibility of ferrule material with the environment in which it will be used is recommended
  • For applications other than the ones list, please consult Dixon
  • For discharge and suction service, commonly used in the transfer of fuel to homes, airplanes, ships, etc
WARNING: Cancer and Reproductive Harm —
www.p65warnings.ca.gov
WARNING: Cancer and Reproductive Harm —
www.p65warnings.ca.gov

Specifications
More Information
Manufacturer Part Number R125CS-A
Manufacturer Dixon Valve & Coupling
Brand Name DIXON
Length (in) 1.25
Height (in) 2.0312
Diameter 2-1/32 in
Inside Diameter 1-1/4 in
Outside Diameter 1-51/64 to 1-54/64 in
Domestic/Import Domestic
Material Brass
Standard Approvals
  • API Certified
  • Tested and Compliant with API 1629 6th Edition
  • PROP65: This product contains a chemical known to the state of California to cause birth defects or other reproductive harm
Warnings
  • This product contains a chemical known to the State of California to cause birth defects or other reproductive harm
  • Do not use in connection with drinking water
  • Wash hands after handling
Warranty Limited
Package Quantity 1/Each
