Dixon® R2BSS-A 520-H Ferrule, 2 in ID x 2-35/64 to 2-38/64 in OD Nominal, Hose, 2-5/32 in L, 304 Stainless Steel, Domestic
Manufacturer #R2BSS-A
In stock
List Price:
$23.35
$23.35
Quantity Break Pricing may apply in the cart
HSI
R2BSS-A-10639
Product Overview
Dixon® Ferrule, Series: 520-H, 2 in ID x 2-35/64 to 2-38/64 in OD Nominal, Hose End Style, 2-5/32 in Length, 304 Stainless Steel, 2-13/16 in dia, Domestic
Features
- Coupling procedures, ferrule recommendations and API test data are available upon request, please contact Dixon®
- Consult Dixon® for other hose OD's
- Do not interchange with other manufacturer's fittings
- Dixon® holedall stems and ferrules are specifically designed to be used together as a coupling system
- Do not use a wrench or vice on ferrule
- Holedall couplings, regardless of coupling style, are never to be used for steam service at any pressure
- Holedall fittings are not to be used with cable reinforced high pressure hose, 4 or 6 braid wire hydraulic hose or any other service not listed in the recommendations
- Strict adherences to ferrule OD range (Internally Expanded) for each hose end to be assembled is essential for satisfactory performance
- Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting
- The assembly's (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure
- Media being transported through the hose should be compatible with the stem material
- Compatibility of ferrule material with the environment in which it will be used is recommended
- For applications other than the ones list, please consult Dixon®
- For discharge and suction service, commonly used in the transfer of fuel to homes, airplanes, ships, etc
Specifications
Manufacturer Part Number | R2BSS-A |
---|---|
Manufacturer | Dixon Valve & Coupling |
Brand Name | DIXON |
Length (in) | 2.156 |
Height (in) | 2.8125 |
Inside Diameter | 2 in |
Outside Diameter | 2-35/64 to 2-38/64 in |
Domestic/Import | Domestic |
Material | 304 Stainless Steel |
Standard Approvals |
|
Warranty | Limited |
Package Quantity | 1/Each |
