Dixon® R2DSS-A 520-H Ferrule, 2 in ID x 2-43/64 to 2-46/64 in OD Nominal, Hose, 2-5/32 in L, 304 Stainless Steel, Domestic

Manufacturer #R2DSS-A
In stock
List Price: $23.35
$23.35
Quantity Break Pricing may apply in the cart
HSI
R2DSS-A-10639
Product Overview
Dixon® Ferrule, Series: 520-H, 2 in ID x 2-43/64 to 2-46/64 in OD Nominal, Hose End Style, 2-5/32 in Length, 304 Stainless Steel, 2-15/16 in dia, Domestic

Features
  • Coupling procedures, ferrule recommendations and API test data are available upon request, please contact Dixon®
  • Consult Dixon® for other hose OD's
  • Do not interchange with other manufacturer's fittings
  • Dixon® holedall stems and ferrules are specifically designed to be used together as a coupling system
  • Do not use a wrench or vice on ferrule
  • Holedall couplings, regardless of coupling style, are never to be used for steam service at any pressure
  • Holedall fittings are not to be used with cable reinforced high pressure hose, 4 or 6 braid wire hydraulic hose or any other service not listed in the recommendations
  • Strict adherences to ferrule OD range (Internally Expanded) for each hose end to be assembled is essential for satisfactory performance
  • Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting
  • The assembly's (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure
  • Media being transported through the hose should be compatible with the stem material
  • Compatibility of ferrule material with the environment in which it will be used is recommended
  • For applications other than the ones list, please consult Dixon®
  • For discharge and suction service, commonly used in the transfer of fuel to homes, airplanes, ships, etc
WARNING: Cancer and Reproductive Harm —
www.p65warnings.ca.gov
WARNING: Cancer and Reproductive Harm —
www.p65warnings.ca.gov

Specifications
More Information
Manufacturer Part Number R2DSS-A
Manufacturer Dixon Valve & Coupling
Brand Name DIXON
Length (in) 2.156
Height (in) 2.9375
Diameter 2-15/16 in
Inside Diameter 2 in
Outside Diameter 2-43/64 to 2-46/64 in
Domestic/Import Domestic
Material 304 Stainless Steel
Standard Approvals
  • API Certified
  • Tested and Compliant with API 1629 6th Edition
  • PROP65: This product contains a chemical known to the state of California to cause birth defects or other reproductive harm
Warranty Limited
Package Quantity 1/Each
