Dixon® R4ESS-A 520-H Ferrule, 4 in ID x 4-46/64 to 4-48/64 in OD Nominal, Hose, 3-27/32 in L, 304 Stainless Steel, Domestic

Manufacturer #R4ESS-A

In stock

Be the first to review this product

List Price: $142.04

$142.04

Quantity Break Pricing may apply in the cart

HSI

R4ESS-A-10639

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Product Overview

Dixon® Ferrule, Series: 520-H, 4 in ID x 4-46/64 to 4-48/64 in OD Nominal, Hose End Style, 3-27/32 in Length, 304 Stainless Steel, 5-3/32 in dia, Domestic

Features

Coupling procedures, ferrule recommendations and API test data are available upon request, please contact Dixon®
Consult Dixon® for other hose OD's
Do not interchange with other manufacturer's fittings
Dixon® holedall stems and ferrules are specifically designed to be used together as a coupling system
Do not use a wrench or vice on ferrule
Holedall couplings, regardless of coupling style, are never to be used for steam service at any pressure
Holedall fittings are not to be used with cable reinforced high pressure hose, 4 or 6 braid wire hydraulic hose or any other service not listed in the recommendations
Strict adherences to ferrule OD range (Internally Expanded) for each hose end to be assembled is essential for satisfactory performance
Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting
The assembly's (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure
Media being transported through the hose should be compatible with the stem material
Compatibility of ferrule material with the environment in which it will be used is recommended
For applications other than the ones list, please consult Dixon®
For discharge and suction service, commonly used in the transfer of fuel to homes, airplanes, ships, etc

WARNING: Cancer and Reproductive Harm —
www.p65warnings.ca.gov

Specifications

More Information
Manufacturer Part Number	R4ESS-A
Manufacturer	Dixon Valve & Coupling
Brand Name	DIXON
Length (in)	3.844
Height (in)	5.094
Diameter	5-3/32 in
Inside Diameter	4 in
Outside Diameter	4-46/64 to 4-48/64 in
Domestic/Import	Domestic
Material	304 Stainless Steel
Standard Approvals	API Certified Tested and Compliant with API 1629 6th Edition PROP65: This product contains a chemical known to the state of California to cause birth defects or other reproductive harm
Warranty	Limited
Package Quantity	1/Each
