Dixon® R75AAS 520-H Scovill Style Ferrule, 3/4 in ID x 1-8/64 to 1-11/64 in OD Nominal, Hose, 1 in L, Brass, Domestic

Manufacturer #R75AAS

Call for availability

List Price: $8.25

$8.25

Quantity Break Pricing may apply in the cart

HSI

R75AAS-10639

Dixon® R75AAS 520-H Scovill Style Ferrule, 3/4 in ID x 1-8/64 to 1-11/64 in OD Nominal, Hose, 1 in L, Brass, Domestic is available to buy in increments of 1

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Product Overview

Dixon® Ferrule, Scovill Style, Series: 520-H, 3/4 in ID x 1-8/64 to 1-11/64 in OD Nominal, Hose End Style, 1 in Length, Brass, 1-9/32 in dia, Domestic

Features

For use with brass internally expanded permanent couplings
H520 fittings are design for internal expansion only
Do not interchange with other manufacturer's fittings
Designed for internal expansion only
Holedall couplings, regardless of coupling style, are never to be used for steam service at any pressure
Holedall fittings are not to be used with cable reinforced high pressure hose, 4 or 6 braid wire hydraulic hose or any other service not listed in the recommendations
Strict adherences to ferrule OD range (Internally Expanded) for each hose end to be assembled is essential for satisfactory performance
Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting
The assembly's (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure
Media being transported through the hose should be compatible with the stem material
Compatibility of ferrule material with the environment in which it will be used is recommended
For applications other than the ones list, please consult Dixon®
Intended for fuel delivery service
Commonly used in the transfer of fuel to homes, airplanes, ships, etc
Recommended for discharge and suction service

WARNING: Cancer and Reproductive Harm —
www.p65warnings.ca.gov

Specifications

More Information
Manufacturer Part Number	R75AAS
Manufacturer	Dixon Valve & Coupling
Brand Name	DIXON
Length (in)	1
Height (in)	1.2812
Standard Approvals	PROP65: This product contains a chemical known to the state of California to cause birth defects or other reproductive harm
Type	Scovill Style
Warranty	Limited
Domestic/Import	Domestic
Material	Brass
Outside Diameter	1-8/64 to 1 in - 11/64 in
Inside Diameter	3/4 in
Package Quantity	1/Each
