Harrington SNERM003S-L/S-15 Electric Chain Hoist 1-Phase with Motorized Trolley, 0.25 ton Load, 5 mm Chain Rope, 15 ft Lifting

Manufacturer #SNERM003S-L/S-15

Call for availability

$9,049.61

Quantity Break Pricing may apply in the cart

HSI

SNERM003S-L/S-15-11188

Harrington SNERM003S-L/S-15 Electric Chain Hoist 1-Phase with Motorized Trolley, 0.25 ton Load, 5 mm Chain Rope, 15 ft Lifting is available to buy in increments of 1

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Product Overview

Harrington electric chain hoist, 1-phase 1-speed, series: SNERM, 0.25 ton load, 5 mm chain/rope, 15 ft lifting height, 14 FPM lift, 14.6 in minimum between hooks, 0.9 in hook opening, pushbutton cord control, pull rotor motor brake, 0.34 hp power, 115/230V AC, 7.7/3.9 A, yellow, 22-3/16 in L x 15-19/32 in W x 11-5/8 in D housing dimensions. Harrington SNER electric chain hoists are built, for eXTreme™ duty applications that require 1-phase power.

Features

60 min, H4 rated, fan cooled motor for the most demanding applications
Pull rotor electric brake is self-adjusting and virtually maintenance free
Compact, low headroom design
Completely sealed body, suitable for harsh indoor or outdoor environments - IP55 rated
Ability to accommodate very long lifts

Specifications

More Information
Manufacturer Part Number	SNERM003S-L/S-15
Manufacturer	Harrington Hoists, Inc
Brands	HARRINGTON
Length (in)	40
Width (in)	33
Height (in)	25
Product Type	Bare Tool
Standard Approvals	ASME H4 ASME B30.16 NFPA 70 ASME HST-1
Type	1-Phase 1-Speed
Package Quantity	1/Each
