Harrington SNERM010S-L/S-20 Electric Chain Hoist 1-Phase with Motorized Trolley, 1 ton Load, 8 mm Chain Rope, 20 ft Lifting Height, 1.2 hp Power Rating, 115/230 VAC

Manufacturer #SNERM010S-L/S-20
Call for availability
List Price: $11,297.04
$11,297.04
Quantity Break Pricing may apply in the cart
HSI
SNERM010S-L/S-20-11188
Product Overview
Harrington electric chain hoist, 1-phase 1-speed, series: SNERM, 1 ton load, 8 mm chain/rope, 20 ft lifting height, 14 FPM lift, 17.7 in minimum between hooks, 1.2 in hook opening, pushbutton cord control, pull rotor motor brake, 1.2 hp power, 115/230 VAC, 23.9/12 A, yellow, 26-15/16 in L x 15-19/32 in W x 14-11/16 in D housing dimensions. Harrington SNER electric chain hoists are built, for extreme duty applications that require 1-phase power.

Features
  • 60 min, H4 rated, fan cooled motor for the most demanding applications
  • Pull rotor electric brake is self-adjusting and virtually maintenance free
  • Compact, low headroom design
  • Completely sealed body, suitable for harsh indoor or outdoor environments - IP55 rated
  • Ability to accommodate very long lifts

Specifications
More Information
Manufacturer Part Number SNERM010S-L/S-20
Manufacturer Harrington Hoists, Inc
Brand Name HARRINGTON
Length (in) 40
Width (in) 33
Height (in) 25
Type 1-Phase 1-Speed
Standard Approvals
  • ASME H4
  • ASME B30.16
  • NFPA 70
  • ASME HST-1
Package Quantity 1/Each
