Harrington SNERP005L-10 Electric Chain Hoist 1-Phase with Push Trolley, 0.5 ton Load, 6.3 mm Chain Rope, 10 ft Lifting Height, 0.34 hp Power Rating, 115/230 VAC

Manufacturer #SNERP005L-10
Call for availability
List Price: $3,170.34
$3,170.34
Quantity Break Pricing may apply in the cart
HSI
HOI70495
Product Overview
Harrington electric chain hoist, 1-phase, series: SNERP, 0.5 ton, 6.3 mm, 10 ft lifting height, 7 FPM lift speed, 15.4 in minimum between hooks, 0.9 in hook opening, 1-speed/pushbutton cord control, pull rotor motor brake, 0.34 hp, 115/230 VAC, 7.7/3.9 A, 15.4 in headroom, 95 lb, yellow, 22-1/4 in L x 13 in W x 6-5/8 in D housing.

Features
  • 60 min, H4 rated, fan cooled motor for the most demanding applications
  • Pull rotor electric brake is self-adjusting and virtually maintenance free
  • Compact, low headroom design
  • Completely sealed body, suitable for harsh indoor or outdoor environments - IP55 rated
  • Ability to accommodate very long lifts

Specifications
More Information
Manufacturer Part Number SNERP005L-10
Manufacturer Harrington Hoists, Inc
Brand Name HARRINGTON
Length (in) 22.25
Width (in) 13
Height (in) 6.625
Color Yellow
Standard Approvals
  • ASME H4
  • ASME B30.16
  • NFPA 70
  • ASME HST-1
Type 1-Phase
Load Capacity 0.5 ton
Voltage 115/230V AC
Hook Opening 0.9 in
Lifting Height 10 ft
Package Quantity 1/Each
