Harrington SNERP010S-15 Electric Chain Hoist 1-Phase with Push Trolley, 1 ton Load, 8 mm Chain Rope, 15 ft Lifting Height, 1.2 hp Power Rating, 115/230 VAC
Manufacturer #SNERP010S-15
Call for availability
List Price:
$6,836.27
$6,836.27
Quantity Break Pricing may apply in the cart
HSI
SNERP010S-15-11188
Product Overview
Harrington electric chain hoist, 1-phase, series: SNERP, 1 ton, 8 mm, 15 ft lifting height, 14 FPM lift speed, 19-1/2 in minimum between hooks, 1.2 in hook opening, 1-speed/pushbutton cord control, pull rotor motor brake, 1.2 hp, 115/230 VAC, 23.9/12 A, 19-1/2 in headroom, 184 lb, yellow, 26-7/8 in x 16-1/2 in W x 8-5/16 in D housing.
Features
- 60 min, H4 rated, fan cooled motor for the most demanding applications
- Pull rotor electric brake is self-adjusting and virtually maintenance free
- Compact, low headroom design
- Completely sealed body, suitable for harsh indoor or outdoor environments - IP55 rated
- Ability to accommodate very long lifts
Specifications
Manufacturer Part Number | SNERP010S-15 |
---|---|
Manufacturer | Harrington Hoists, Inc |
Brand Name | HARRINGTON |
Length (in) | 26.875 |
Width (in) | 16.5 |
Height (in) | 8.3125 |
Color | Yellow |
Standard Approvals |
|
Type | 1-Phase |
Load Capacity | 1 ton |
Voltage | 115/230V AC |
Hook Opening | 1.2 in |
Lifting Height | 15 ft |
Package Quantity | 1/Each |
