Crosby® 1018847 Chain Shackle, Series: S-215, 0.75 ton Load, 5/16 in, 3/8 in dia Round Pin, Self-Colored

Manufacturer #1018847

Call for availability

Be the first to review this product

List Price: $11.46

$11.46

Quantity Break Pricing may apply in the cart

HSI

1018847-13143

UPC #:662547188476

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Product Overview

Crosby® Chain Shackle, Series: S-215, 0.75 ton Load, 5/16 in Size, 3/8 in Pin dia, Round Pin, 1.07 in Inner Length, 0.53 in Inner Width, 0.53 in Opening, 3/4 in Eye Outer, 1.91 in OAL, 1.63 in OAW, Carbon Steel Body, Alloy Pin, Self-Colored

Features

Working load limit permanently shown on every shackle
Shackles are quenched and tempered and can meet DNV impact requirements of 42 J at -20กC
Look for the Red Pin® the mark of genuine Crosby® quality
For tie down, towing, suspension or lifting applications where the load is strictly applied in-line

Specifications

More Information
Manufacturer Part Number	1018847
Manufacturer	Crosby Group
Brand Name	CROSBY
UPC	662547188476
Length (in)	1.91
Width (in)	1.63
Series	S-215
Standard Approvals	ABS/DNV/Lloyds/CE Certified Federal Spec RR-C-271F Type IVA Grade A Class 1
Working Load Limit (ton)	0.75
Finish	Self-Colored
Shackle Size	5/16 in
Eye Outer Size (in)	3/4 in
Opening Size	0.53 in
Inner Width	0.53 in
Inner Length	1.07 in
Pin Diameter	3/8 in
Package Quantity	1/Each
