Dixon® External Swage Ferrule, Standard, Series: Holedall™, 5 in ID x 5-61/64 to 6-4/64 in OD Nominal, Hose, 6-1/8 in Length, Carbon Steel, Plated, 6-5/8 in dia, Domestic
Features
- The coupling system requires no bolts and results in a clean coupling with no protrusions
- The holedall coupling provides long lasting efficiency and safety
- Style F ferrules are used with all standard length external swage stems - TM, TMR, TP, TPR, TG and TGR styles
- The selection of ferrules is very important to achieve proper coupling-to-hose assembly
- Dixon®holedall stems and ferrules are specifically designed to be used together as a coupling system
- Due to differences in dimensions and tolerances, for safety reasons, do not use other manufacturer's stems or ferrules with Dixon®holedall products
- Do not use a wrench or vice on ferrule
- The selection of ferrules is very important to achieve the proper coupling-to-hose assembly
- Holedall couplings, regardless of coupling style, are never to be used for steam service at any pressure
- Holedall fittings are not to be used with cable reinforced high pressure hose, 4 or 6 braid wire hydraulic hose or any other service not listed in the recommendations
- Externally swaged holedall couplings, to perform satisfactorily, must be applied properly in accordance with Dixon®s assembly procedures, using correct die and ferrule for that particular hose end OD
- Dixon®s die and ferrule recommendation guide is to be used to select correct dies and ferrules
- Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting
- The assembly's (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure
- Media being transported through the hose should be compatible with the stem material
- Compatibility of ferrule material with the environment in which it will be used is recommended
- Do not use in connection with drinking water
- Wash hands after handling
